2019 Hyundai Sonata Cabin Air Filter Replacement

The 2019 Hyundai Sonata's cabin air filter is an essential component that helps maintain clean air inside your vehicle. Located behind the glove box, this filter removes dust, pollen, and other airborne particles from the air entering the cabin. Regular replacement is crucial for optimal air quality and HVAC system performance.
Replacement Interval
It's recommended to replace the cabin air filter in your 2019 Hyundai Sonata every 12,000 miles or once a year, whichever comes first. However, if you frequently drive in dusty or polluted areas, you may need to replace it more often.
Filter Location
The cabin air filter is situated behind the glove box on the passenger side of the vehicle. Accessing it requires removing the glove box, which is a straightforward process that doesn't require any special tools.
Replacement Procedure
Step 1: Prepare the Glove Box
1. Open the glove box and empty its contents.
2. Locate the damper arm on the right side of the glove box.
3. Squeeze the tabs on the damper arm and disconnect it from the glove box.
Step 2: Remove the Glove Box
1. Find the stoppers on both sides of the glove box interior.
2. Turn the stoppers counterclockwise to remove them.
3. Gently push the sides of the glove box inward and lower it down.
Step 3: Access the Filter
1. Locate the rectangular filter housing behind the glove box.
2. Find the small lever on the passenger side of the housing.
3. Pull the lever towards the driver's side to release the housing cover.
Step 4: Replace the Filter
1. Remove the old filter by pulling it straight out.
2. Note the airflow direction indicated on the old filter.
3. Insert the new filter with the airflow arrow pointing downward.
4. Ensure the filter fits snugly in the housing.
Step 5: Reassemble
1. Replace the filter housing cover, ensuring it clicks into place.
2. Lift the glove box back into position.
3. Reinsert the stoppers on both sides, turning them clockwise.
4. Reattach the damper arm to the glove box.
5. Close the glove box and ensure it operates smoothly.
Choosing the Right Filter
When selecting a replacement filter, you have two main options:
1. OEM Filter: The Hyundai part number for the 2019 Sonata cabin air filter is 97133-C2000.
2. Aftermarket Filters: These can be more affordable and may offer additional features like activated carbon for odor reduction.
Filter Type | Pros | Cons |
---|---|---|
OEM | Guaranteed fit, Hyundai quality | More expensive |
Aftermarket | Often cheaper, May have extra features | Varying quality, Potential fit issues |
Maintenance Tips
- Inspect regularly: Check your filter every few months for excessive dirt or debris.
- Vacuum the housing: Before installing a new filter, vacuum the filter housing to remove any accumulated dirt.
- Consider your environment: If you live in a dusty area or have allergies, you might benefit from more frequent replacements.
By following these steps and maintaining your cabin air filter, you'll ensure that the air inside your 2019 Hyundai Sonata remains clean and fresh, contributing to a more comfortable and healthier driving experience.
