Replacing the rear wheel speed sensor in a 2015 Hyundai Sonata is essential for maintaining the functionality of the Anti-lock Braking System (ABS) and Electronic Stability Control (ESC). This guide provides step-by-step instructions to help you perform the replacement safely and effectively.

Understanding the Rear Wheel Speed Sensor

The rear wheel speed sensor measures the rotational speed of the wheel and sends this information to the vehicle's Engine Control Module (ECM). If this sensor fails, it can trigger warning lights on your dashboard, such as the ABS or brake light, indicating a malfunction in the braking system.

Tools and Materials Needed

  • Tools:

- Floor jack and jack stands

- 10mm socket

- 12mm socket

- Torque wrench

- Flathead screwdriver

- Phillips screwdriver

  • Materials:

- New rear wheel speed sensor

- Penetrating oil (if necessary)

Step-by-Step Replacement Process

1. Preparation:

- Park your vehicle on a flat surface and engage the parking brake.

- Disconnect the negative battery terminal using a 10mm socket to prevent electrical shorts.

2. Lift the Vehicle:

- Use a floor jack to lift the rear of the vehicle. Secure it with jack stands for safety.

3. Remove the Wheel:

- Using a 21mm socket, remove the lug nuts and take off the rear wheel to access the sensor.

4. Locate the Sensor:

- The rear wheel speed sensor is typically located near the brake assembly, attached with one or two bolts.

5. Remove the Old Sensor:

- Disconnect any clips or wiring harnesses connected to the sensor.

- Use a 10mm socket to remove the bolt securing the sensor.

- Gently wiggle and pull out the old sensor from its housing.

6. Install the New Sensor:

- Before installing, ensure that any dirt or debris is cleaned from the sensor's mounting area.

- Insert the new sensor into place, aligning it properly.

- Secure it with the bolt and tighten it using a torque wrench to manufacturer specifications.

7. Reconnect Wiring:

- Reattach any clips or wiring harnesses that were disconnected during removal.

8. Reinstall the Wheel:

- Place the wheel back onto the hub and hand-tighten lug nuts.

- Lower the vehicle back to ground level and torque lug nuts to 80 ft-lbs in a star pattern.

9. Reconnect Battery:

- Reconnect the negative battery terminal securely.

10. Test Drive:

- Start your vehicle and take it for a test drive to ensure that all warning lights are off and that braking functions correctly.

Important Considerations

  • Always wear safety gear when working on your vehicle.
  • If you encounter resistance when removing the old sensor, apply penetrating oil and allow it to soak before attempting removal again.
  • Ensure that all connections are secure after installation to prevent future issues.

FAQs About Rear Wheel Speed Sensor Replacement

    • What symptoms indicate a faulty wheel speed sensor?
      Common symptoms include illuminated ABS or brake warning lights, erratic speedometer readings, or issues with traction control.
    • Do I need to reset any codes after replacing the sensor?
      Yes, it is advisable to use an OBD-II scanner to clear any fault codes after replacement.
    • How often should I replace my wheel speed sensors?
      While there is no set schedule, sensors should be inspected regularly for wear, especially if warning lights appear.
